Grand Superior armoured door

Flexibility and security with concealed hinges

  • Burglar resistance class 3
  • Next concealed hinges
  • Opening up to 100°
  • Adjustable on 2 axes
  • LA standard: 800-850-900×2100 mm / Max. single leaf LA: 1000×2400 mm

*Please login or register for download

Easy to install, safe, high performance, beautiful to look at thanks to its concealed hinges

Certifications

Burglar resistance

Class 3, optionally extendible as per UNI EN 1627 (from LA 728×1745 to LA 1000×2400 – if necessary, specify required certification at time of order).

Acoustic

RW=39 dB upgradeable to RW=45 dB (with Sigillo kit). Up to LA 1000×2400.

Thermal

UD= 2.3 W/m²K with wood-based 7 mm panels. Upgradeable to UD= 1.1 W/m²K (with Clima kit and 16 mm wood-based panels). Up to LA 1000×2400.

Air, water, wind

2/npd/5C upgradeable to 4/7A/5C (with Sigillo kit). Up to LA 1000×2400.

Next hinge.
New design but the same quality and the same ease of installation.

The new Next concealed hinges have been specifically designed to replace and improve the Superior series while retaining its quality and high performance levels. The hinge is adjustable on 2 axes (height and depth). Door opening up to 100 degrees. Concealed hinges visible with open door with silver finish.

Grand Superior models

S16

Cylinder lock with Duo anti-drill and anti-bumping cylinder (class 2), with knob, protected by anti-drill and pipe resistant defender (class 4).
11 securing points: 6 moving points, 1 spring latch, 4 fixed hinge bolts.
Key system: 1 recodable installation key (not unified) + 3 master keys with Security Card.

S17

Double cylinder lock with standard-fitted daisy-chain block (the second turn of the master/upper cylinder also prevents the operation of the service/lower cylinder) with double Duo anti-drill, anti-bumping cylinder (class 2) in master/service configuration, both with knobs and both protected by anti-drill, anti-pipe defender (class 4).
12 securing points: 7 moving points, 1 spring latch, 4 fixed hinge bolts.
Key system: 1 recodable installation key (not unified) for master cylinder + 1 recodable installation key (not unified) for service cylinder + 3 master keys with Security Card + 3 service keys with Security Card.

S18

Electromechanical lock (Easy version) with Duo key/key anti-drill and anti-bumping cylinder (class 2), protected by anti-drill and anti-pipe defender (class 4). Alkaline batteries (non-rechargeable), external TAG reader, internal keypad as standard.
11 securing points: 6 moving points, 1 spring latch, 4 fixed hinge bolts
Key system: 3 transponder keys + 1 recodable installation key (not unified) + 3 master keys with Security Card.
